网络机柜服务器机柜TS

主要性能 The main performance
◆ 符合ANSI/EIA RS-310-D、 IEC297-2、 DIN41491;  PART1、DIN41494。◆ PART7、GB/T3047.2-92标准。◆ 材料：SPCC优质冷轧钢板制作；◆ 防护等级：IP20。◆ 承载：静载800KG。 ◆ 机柜采用框架结构，静载承重达800KG。◆ 快开侧门，方便安装和维修。◆ 托盘可根据用户要求， 上下自由调整。◆ 外型美观，工艺精湛、尺度精密，极富时代气息。◆ 钢化玻璃前门及高密度网孔后门，可同时解决设备保护、通风散热、外部观察机器运行状态三方面的使用要求。 ◆ 可同时安装脚轮和支撑脚。 ◆ 高级旋把机柜门锁。 ◆ 齐全的可选配件。◆ 主体颜色为国际流行电脑灰和黑色两大系列。◆ 可关闭的上部、下部多处走线通道，底部走线孔尺寸可按需调整。
◆In accordance with ANSIN/EIA RS-310-D、IEC297-2、DIN41491; PART1、DIN41494.◆ PART7、GB/T3047.2-92 standard and compatible to ETSI standard. ◆ Material: SPCC high-quality cold steel rolling plates. ◆ Grade of Protection: IP20. ◆ Load: stationary load 800kg. ◆ The cabinet adopts frame structure, with 800KG static load. ◆ The quick open structured side door is easy to install and maintain. ◆ The tray can be adjusted freely up and down according to customer’s requirement. ◆ Attractive shape, exquisite workmanship, precise dimension, and full of modern taste. The front door which is made of toughened glass and back door with high density meshes, can meet requirements of equipment protection, ventilation and that dissipation, and observing running status of the machine at the same time. ◆ It can be installed with casters and support feet at the same time. ◆ High-class cabinet door lock with revolving handle. ◆ Complete optional fittings ◆ Main color includes two series of international fashionable computer gray and black. ◆ Several places of cable laying channel go through the top and the bottom, part can be closed, and dimension of the bottom cable-laying holes can be adjusted according to requirement.
